Engine:
All three 3600 Series tractor models feature impressive turbo-charged SisuDiesel engines. These ingeniously designed 3-cylinder engines deliver more torque, greater reliability and superior fuel efficiency – no matter what the job.


Transmission:
Massey Ferguson 3600 Series tractors give you a choice of shuttling transmissions, to complement your operation and the way you work. Whether you choose the standard 8 x 8 SynchroShuttle transmission or the available 12 x 12 PowerShuttle, you’ll get a powertrain that gives you smoother, virtually effortless gear changes. So, no matter what job you’re tackling, you can be sure you’ll get it done faster and easier, every time.


Hydraulics:
Every 3600 series tractor features a dependable open center hydraulic system to give you all the power and control you need to get the job done. With two dedicated hydraulic gear pumps – and a combined total flow of 22.4 GPM – you can count on maximum hydraulic flow where you need it and when you need it. The 15.8 GPM main pump delivers plenty of muscle to the auxiliary hydraulic remotes and the 3-point hitch, for faster cycle times that let you do more work in less time. A second 6.6 GPM pump ensures precise, low-effort steering, even in adverse conditions, without diverting flow from the main pump.


Two 3-position remote valves with spring return to neutral are standard. Three remote valves – one 3-position spring return to neutral and two 4-position kickout and float – are optional.


For even greater productivity, the factory-installed, ergonomic joystick includes mid-mounted valve and couplers, so loader work is a breeze and loader hookup is a snap.


3 Point Hitch:
Strong 3-point linkage on every 3600 Series tractor boasts an impressive 5,512 pounds of lift capacity, so you can count on optimum implement accuracy and responsive control, even with the largest implements. Control systems include position control for implement working height, draft-sensing control for working depth, and rate of drop control, to protect implements when lowering or transporting. And all controls are conveniently placed at the operator’s right hand, so you work more efficiently with any mounted implement.


Standard cross-drilled ball ends allow you to switch between Category I and II implements. Telescopic stabilizers let you hook up implements and adjust side-to-side sway to suit the implement. With the optional extendable lower links, it’s even easier to connect to any implement or attachment.


PTO:
The standard 540 independent PTO makes it easy to use a wide array of implements. For those tasks requiring less power, choose the optional 540 economy PTO.


Thanks to the standard independent PTO, you’ll get optimum productivity and performance from all your implements. Engage or disengage the PTO on the fly, thanks to an ergonomically controlled hydraulic clutch that works with just the touch of a finger.


Some jobs, like spraying or light mowing, require less than your tractor’s fully rated PTO horsepower. Thanks to the optional 2-speed 540/540E economy PTO, you can conserve diesel, without affecting performance. And that makes a hard day’s work easier on your fuel tank – and on your budget.


Operator's Area:
Footstep and cab versions are available for every 3600 series tractor. The spacious, uncluttered footstep design provides operators with plenty of room to climb aboard and settle into the adjustable operator’s seat. Controls and instrumentation are thoughtfully placed and easy to read, so you work more efficiently, with less operator fatigue. And the sleekly sloped hood enhances visibility, for less strain, greater safety and improved efficiency with jobs like loader work.


Comfort and convenience is also found inside the factory installed cab tractors.


Step effortlessly into the quiet, spacious iso-mounted cab through either of two wide entry doors. Have a seat in the deluxe adjustable fabric-covered seat – complete with arm rests, beverage holder and retractable seat belt. Then adjust the telescopic, tilt steering column to fit the way you drive.


Adjust and direct the vents on the standard HVAC system, to create a comfort zone inside the cab, no matter what the weather. And work safer and smarter, thanks to features like front and rear work lights, left and right exterior mirrors, curved rear side windows, swing-out rear window, a rear cable entry point and an optional rear wiper.


Serviceability:
Just flip up the one-piece hood on your 3600 Series tractor, and you’ll have instant access to all your routine maintenance and service points. The air cleaner, heavy-duty battery, radiator, A/C condenser, and oil and fuel filters are right at your fingertips, so you can keep tabs on important tractor functions regularly. In addition, the engine oil dipstick, filter and fill are all conveniently clustered on the same side of the engine, so maintenance and service require less time and effort.


Accessories:
A wide variety of accessories allow tractors to be tailored to best fit many applications. Popular, convenience enhancing features include extendible lower links, factory installed joystick, air suspension seat, 540/540E PTO, horizontal exhaust, and additional work lights. With these choices each tractor is sure to provide the versatility needed for any job.
